24 to 220 kVA

Diesel Generator Sets

The 24 – 220 kVA range provides reliable power for today’s world with a competitive offering that delivers everything you need. Providing unrivalled quality, the 24 – 220 kVA range of products offers a trusted performance with an enhanced choice of options, optimising the range for a variety of diverse applications and environments.

Designed with the demands of today’s world in mind, the new generator sets will deliver power solutions in all sectors, from industry and retail to finance and healthcare.

All models are tested within standard reference conditions 25ºC (77ºF) Air Inlet Temp, 100m (328ft) A.S.L. 30% relative humidity.

These diesel generator set models are not compliant with EU Stage II Emission Legislation.

Generator set name kVA @ 50 Hz kW @ 50 Hz kVA @ 60 Hz kW @ 60 Hz
P 26-3S 24.0 / 26.0 24.0 / 26.0 – / – – / –
P 33-3 30.0 / 33.0 24.0 / 26.4 33.8 / 37.5 27.0 / 30.0
P40-3S 36.0 / 40.0 36.0 / 40.0 40.0 / 45.0 40.0 / 45.0
P 50-3 45.0 / 50.0 36.0 / 40.0 50.0 / 56.3 40.0 / 45.0
P 50-5S 45.0 / 50.0 45.0 / 50.0 50.0 / 55.0 50.0 / 55.0
P 55-3 50.0 / 55.0 40.0 / 44.0 56.3 / 62.5 45.0 / 50.0
P 65-5 60.0 / 65.0 48.0 / 52.0 68.8 / 75.0 55.0 / 60.0
P 88-3 80.0 / 88.0 64.0 / 70.4 90.0 / 100.0 72.0 / 80.0
P110-3 100.0 / 110.0 80.0 / 88.0 113.0 / 125.0 90.4 / 100.0
P150-5 135.0 / 150.0 108.0 / 120.0 150.0 / 165.0 120.0 / 132.0
P165-5 150.0 / 168.8 120.0 / 135.0 165.0 / 187.5 132.0 / 150.0
P200-3 180.0 / 200.0 144.0 / 160.0 – / – – / –
P220-3 200.0 / 220.0 160.0 / 176.0 – / – – / –

These diesel generator set models are compliant with EU Stage II Emission Legislation

Generator set name kVA @ 50 Hz kW @ 50 Hz kVA @ 60 Hz kW @ 60 Hz
P90-3S 82.0 / 90.0 82.0 / 90.0 90.0 / 99.5 90.0 / 99.5
P 26-6S† 24.0 / 26.0 24.0 / 26.0 – / – – / –
P 33-6† 30.0 / 33.0 24.0 / 26.4 – / – – / –
P40-4S 36.0 / 40.0 36.0 / 40.0 – / – – / –
P 50-4 45.0 / 50.0 36.0 / 40.0 – / – – / –
P 55-6S† 45.0 / 50.0 45.0 / 50.0 – / – – / –
P 55-4 50.0 / 55.0 40.0 / 44.0 – / – – / –
P65-6† 60.0 / 65.0 48.0 / 52.0 – / – – / –
P 88-6† 80.0 / 88.0 64.0 / 70.4 – / – – / –
P 90-6S† 82.0 / 90.0 82.0 / 90.0 – / – – / –
P110-6† 100.0 / 110.0 80.0 / 88.0 – / – – / –
